28 Ton Terex BT28106
Boom Truck
Unit: 9792
Next Step..

For more Information:

Call

877-321-3710
or Click Below!
$
2
Apply for financing!
3
Give me a value on on my trade-in!
Request Info!
Specifications
Crane
ManufacturerTerex
Crane ModelBT28106
Capacity28 ton
Boom Length106'
Total Tip Height116'
Outriggers"K" Frame Hydraulic Front Outriggers with Out/Down Rears
BodyHeavy Duty 22' x 8'6" Wood
Crane Warranty24 Month Terex Factory Parts And Labor Warranty
Additional Crane Features
  • Terex Patented Keel Shaped Boom
  • Greer Insight LMI With Audio/Visual Operator's Display
  • Internally Run Anti-Two Block **NO WIRES!!**
  • 360 degree standard load chart
Truck
ManufacturerKenworth
Truck ModelT470
EnginePaccar PX-9 Turbo Diesel
Horsepower350
TransmissionFuller RTO-11908LL 10-Speed Manual Transmission
GVW60000
WarrantyStandard Kenworth Factory Warranty
Additional Truck Features
  • PACCAR 1000W Block Heater
  • Alcoa Polished Aluminum Wheels
  • Bendix Air Dryer
  • Kenworth AM/FM/WB/CD Radio
  • Electric Door Locks
  • Airlocked Aluminum Cab
  • LED Stop/Turn/Rear Lights
  • Tapered Chrome Steel Bumper
Description
Year2015
DescriptionBrand New Terex BT28106 28 ton crane on 2015 Kenworth T470
StatusUsed
Features

CRANE

  • NEW TEREX BT28106
  • 28 TON CAPACITY
  • FOUR-SECTION 106' KEEL DESIGNED BOOM
  • 116FT WORKING SHEAVE TIP HEIGHT 163' TIP WITH OPTIONAL OFFSETABLE JIB
  • 3-SECTION PTO DRIVEN VANE PUMP
  • STANDARD 2-SPEED PLANETARY HOIST
  • ROTATION PLANETARY GEARBOX
  • GREER "INSIGHT" RATED CAPACITY LIMITER SYSTEM WITH DIGITAL DISPLAY & INTEGRATED WORK AREA DEFINITION
  • INTERNALLY RUN ANTI-TWO BLOCK WIRE
  • K-PATTERN FRONT HYDRAULIC OUTRIGGERS
  • HYDRAULIC OUT/DOWN REAR OUTRIGGERS
  • 315' OF 9/16" WIRE ROPE
  • HEAVY DUTY 22' X 8' 6" BED
  • REMOVABLE BOOM REST
  • PAINTED STANDARD TEREX RED
  • ALL STANDARD EQUIPMENT
  • 24 MONTHS TEREX FACTORY PARTS AND LABOR WARRANTY

TRUCK

  • NEW 2015 KENWORTH T470
  • 350HP PACCAR PX-9 DIESEL WITH TURBO EXHAUST BRAKE
  • 60,000# G.V.W.R.
  • 20,000# FRONT AXLE
  • 40,000# TANDEM REAR AXLE
  • FULLER RTO11908LL 10-SPEED
  • PACCAR 1000W BLOCK HEATER
  • 425/65R22.5 20PR FRONT TIRES
  • 11R22.5 16PR REAR TIRES
  • ALCOA ALUMINUM POLISHED FRONT & OUTSIDE REAR WHEELS (STEEL INNERS)
  • HENDRICKSON RT403 40K REAR SUSPENSION
  • TWO FRONT TOW HOOKS
  • POWER STEERING
  • AIR BRAKES WITH BENDIX
  • ANTI-LOCK BRAKE SYSTEM
  • DUAL BATTERIES
  • BOSCH 160 AMP ALTERNATOR
  • TAPERED CHROME STEEL BUMPER
  • STAINLESS STEEL PERMIT CAB PANELS
  • 3 PACCAR BATTERIES 1400 CCA
  • BATTERY DISCONNECT ON BATTERY BOX
  • LED STOP/TURN REAR LIGHTS
  • 1-PIECE CURVED GLASS WINDSHIELD
  • CRUISE CONTROL
  • AIR CONDITIONING
  • 56 GAL. ALUMINUM FUEL TANK
  • KW AM/FM/CD WEATHERBAND RADIO
  • KW HIGHBACK AIRCUSH DRIVER SEAT
  • KW TOOLBOX HIGHBACK RIDER SEAT
  • ELECTRIC RH & LH DOOR LOCKS
  • DAYLITE DOORS W/ RH PEEPER WINDOW
  • DUAL 8.5" CONVEX HEATED MIRRORS
  • SINGLE AIRHORN UNDER CAB
  • EXTERIOR STAINLESS STEEL SUNVISOR
  • PAINTED KENWORTH RED
  • ALL STANDARD EQUIPMENT
  • STANDARD KENWORTH WARRANTY
Load Chart

BT28106 Jib Retracted Load Chart


BT28106 Jib Extended Load Chart


BT28106 Line Pull Chart


BT28106 Range Diagram


BT28106 Load Chart


BT28106 Area of Operation Diagram
