40 Ton Manitex 40124SHL
Boom Truck
Unit: 40124SHL (S)
$419,900
Next Step..

For more Information:

Call

877-321-3710
or Click Below!
$
2
Apply for financing!
3
Give me a value on on my trade-in!
Request Info!
Specifications
Crane
ManufacturerManitex
Crane Model40124SHL
Capacity40 ton
Boom Length124'
Jib Length55'
Total Tip Height189'
Outriggers4 Hydraulic Out/Down Outriggers with Intermediate and Fully Retracted settings
Body10' Heavy Duty Steel Bed
Crane WarrantyStandard Manitex Factory Warranty
Additional Crane Features

INCLUDED OPTIONS

  • 55 FT 2-SECTION JIB
  • TILTING ENCLOSED CAB W/ HEAT AND A/C
  • FRONT HYDRAULIC STABILIZER
  • 400' 5/8" ROTATION RESISTANT WIRE ROPE
  • (4) 31" x 31" CRIB PLATES
  • (2) CRIB PLATE HOLDING RACKS (EACH HOLDS 2)
Truck
ManufacturerKenworth
Truck ModelT800
EngineCummins ISX15 Turbo Diesel
Horsepower450
TransmissionFuller RTO-16913A 13 Speed Manual
GVW89000
WarrantyStandard Kenworth Factory Warranty
Additional Truck Features
  • Alcoa polished aluminum wheels
  • Full double frame
  • 100 gallon fuel tank
  • Air ride driver's seat
  • AM/FM/USB radio w/ Bluetooth
Description
Year2017
DescriptionManitex 40124SHL 40 Ton on 2017 Kenworth T800 Tri-drive
StatusNew
Features

CRANE

  • MANITEX 40124SHL,
  • 40 TON CAPACITY W/ REAR MOUNTED RIDER SEAT,
  • 124 FT 5-SECTION TELESCOPIC BOOM,
  • 5-SHEAVE QUICK REEVE BOOM HEAD,
  • 189' TIP HEIGHT WITH 55 FT JIB,
  • TILTING ENCLOSED CAB W/ HEAT AND A/C,
  • FREE SWING OPTION WITH FOOT BRAKE,
  • 380' 5/8" ROTATION RESISTANT WIRE ROPE,
  • PILOT OPERATED DUAL AXIS CONTROLLERS,
  • LMI CAPACITY ALERT WITH VISUAL DISPLAY & OVERLOAD SHUT-OFFS,
  • HARDWIRED ANTI-TWO BLOCK SYSTEM,
  • 360 DEGREE AREA OF OPERATION W/ CONTINUOUS ROTATION,
  • 4 HYDRAULIC OUT-AND-DOWN OUTRIGGERS,
  • LOAD CHARTS FOR FULLY EXTENDED/INTERMEDIATE/RETRACTED OUTRIGGERS,
  • 10 FT BED & RETRACTABLE LADDERS,
  • PAINTED STD MANITEX COLORS,
  • ALL STANDARD EQUIPMENT,
  • STANDARD MANITEX FACTORY WARRANTY.


TRUCK

  • NEW 2017 KENWORTH T800,
  • CUMMINS ISX15 - 450 HP TURBO DIESEL ENGINE W/ INTEBRAKE,
  • 20,000# FRONT AXLE,
  • 69,000# TRI-DRIVE REAR AXLES,
  • DANA T69-TRIDEM REAR AXLES,
  • 4.30 REAR AXLE RATIO,
  • TAPERLEAF FRONT AND REAR SPRINGS,
  • FULLER RTO-16913A 13 SPD MANUAL TRANSMISSION,
  • WITH PUMP AND OIL COOLER,
  • 1650 LB-FT TORQUE,
  • 425-65R22.5 20PR FRONT TIRES,
  • 11R-22.5 16 PLY RADIAL REAR TIRES,
  • ALCOA POLISHED ALUMINUM FRONT AND REAR WHEELS,
  • FULL DOUBLE STEEL FRAME,
  • AIR BRAKES W/ ANTI-LOCK BRAKING SYSTEM & BENDIX AIR DRYER,
  • DUAL POWER STEERING GEARS,
  • 3 PACCAR GP31 BATTERIES 2100 C.C.A,
  • FRONT TOW HOOKS,
  • 120V - 1500W IMMERSION BLOCK HEATER,
  • BATTERY JUMPER TERMINAL,
  • PACCAR 12 VOLT STARTER,
  • VERTICAL EXHAUST-STAINLESS STEEL GUARD AND FAIRING,
  • AIR CONDITIONING,
  • AIR HORN,
  • PACCAR 160 AMP ALTERNATOR,
  • 100 GAL ALUMINUM FUEL TANK (RH),
  • 1-11 GALLON D.E.F. TANK,
  • AM/FM/WB/USB RADIO w/ BLUETOOTH,
  • AIR RIDE DRIVER'S SEAT,
  • HEATED STAINLESS STEEL MIRRORS,
  • ONE PIECE CURVED WINDSHIELD,
  • POWER WINDOWS PASSENGER SIDE,
  • COMPLETE GAUGE PACKAGE,
  • PAINTED KENWORTH WHITE (L0006),
  • STD KENWORTH FACTORY WARRANTY.
Specifications
// This is the youtube video URL: http://www.youtube.com/watch?v=nOHHta68DdU $code = "aZQPES8E6d8"; // Get video feed info (xml) from youtube, but only the title | http://php.net/manual/en/function.file-get-contents.php $video_feed = file_get_contents("http://gdata.youtube.com/feeds/api/videos?v=2&q=".$code."&max-results=1&fields=entry(title)&prettyprint=true"); // xml to object | http://php.net/manual/en/function.simplexml-load-string.php $video_obj = simplexml_load_string($video_feed); // Get the title string to a variable $video_str = $video_obj->entry->title; // Output echo $video_str;
Dimensions

40124SHL Dimensions with Chassis

Load Charts
