CRANE

• MODEL 16524S STANDARD - 16.5TM
• 14.2 TM MAXIMUM LIFTING MOMENT
• 7,300# CAPACITY @ 14'1"
• 42'2" MAXIMUM HORIZONTAL OUTREACH
• 52'2" MAXIMUM VERTICAL REACH
• RACK, SLEWING UP TO 410 DEGREES
• HYDRAULIC OUTRIGGERS HORIZONTAL AND VERTICAL - XXL PADS
• CRANE OIL TANK
• DOUBLE LINKAGE
• FIXED OUTRIGGERS PADS
• OIL COOLER 11kW - 12V
• HIGH PRESSURE LINE KIT
• STANDARD DEAD POINT
• PAINTED STANDARD MAC 7005 GREY
• ALL STANDARD EQUIPMENT
• MANITEX STANDARD FACTORY WARRANTY

TRUCK

• NEW 2023 FREIGHTLINER 114SD
• 455HP CUMMINS X12 TURBO DIESEL ENGINE w/ 1550 LB/FT OF TORQUE
• ALLISON 4500RDS-P 6-SPEED AUTOMATIC TRANSMISSION
• PHILLIPS 300 WATT / 115V OIL PRE-HEATER
• PHILLIPS 1500 WATT / 115V BLOCK HEATER
• 20,000 LB FRONT STEER AXLE
• 46,000 LB REAR +13,300 LB TAG AXLE
• 72,000 LB G.V.W.R.
• HENDRICKSON 46K REAR SUSPENSION
• 20K FLAT LEAF FRONT SUSPENSION
• INTERAXLE TANDEM LOCK VALVES
• 425/65R22.5 20 PLY RADIAL FRONT TIRES
• 11R22.5 14 PLY RADIAL REAR TIRES
• AIR BRAKES W/ WABCO 4S/4M ABS SYSTEM
• WABCO AIR BRAKES w/ HEATER & DRYER
• FULL STEEL REINFORCED FRAME
• 3- DTNA 12V 3000 CCA BATTERIES
• ALCOA BRIGHT ALUMINUM WHEELS
• 12V 160AMP ALTERNATOR
• 16.5" CHROMED STEEL BUMPER
• 10'6" VERTICAL EXHAUST WITH BRIGHT UPPER STACK & STAINLESS STEEL TAILPIPE SHIELD & MUFFLER
• 70 GALLON ALUMINUM FUEL TANK
• AIR CAB MOUNTS WITH CHECK VALVE
• STATIONARY BLACK GRILLE W/ ACCENT
• DUAL WEST COAST STLS STL MIRRORS
• COMPOSITE EXTERIOR SUN VISOR
• TINTED DOOR GLASS/1-PIECE WINDSHIELD
• A/C HEAT DEFROSTER & CRUISE CONTROL
• HIGH BACK AIR SUSPENSION DRIVER SEAT
• AM/FM/WB RADIO-USB & AUX. INPUTS & BT
• PAINTED BRIGHT WHITE L0006B
• ALL STANDARD EQUIPMENT
• STANDARD FREIGHTLINER NEW TRUCK WARRANTY
